Current Sense SMD Resistors | element14 New Zealand

element14 offers an extensive selection of current sense surface-mount device (SMD) resistors designed for accurate current monitoring and energy management in various electronic applications. Our range includes both low-resistance values for high precision and high-power options.

Current sense resistors measure current flow by detecting voltage drops, making them critical for circuit protection, power control, and efficiency monitoring. Current sense resistors enable effective monitoring, which is essential in applications like battery charging circuits, where they ensure optimal charging by determining the required current from the power source. These resistors are commonly used in compact, high-performance electronics due to their reliability and accuracy.

element14's current sense SMD resistors are designed to deliver precision and reliability, making them ideal for power supplies, automotive applications, and battery management systems. With their robust construction and high current capabilities, these resistors play a vital role in ensuring the safety and efficiency of electronic devices.

Manufacturer

Resistance

Product Range

Resistor Case / Package

Power Rating

Resistance Tolerance

Resistor Technology

Resistor Type

Temperature Coefficient

Product Length

Voltage Rating

Product Width

Product Height

Operating Temperature Min

Operating Temperature Max

Qualification

Packaging

No Filter(s) Applied

0 Filter(s) Selected

			Price For		Quantity

CSS2H-2512K-2L00F	2576348 Data Sheet RoHS	BOURNS SMD Current Sense Resistor 0.002 ohm CSS2H-2512 Series 2512 [6432 Metric] 5 W ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ $1.270 ($1.4605) 50+ $1.050 ($1.2075) 250+ $0.784 ($0.9016)	Min: 5 / Mult: 5	0.002ohm	CSS2H-2512 Series	2512 [6432 Metric]	5W	± 1%	Metal Strip	-	± 50ppm/°C	6.35mm	-	3.05mm	1.06mm	-55°C	170°C	-
UCR01MVPFLR390	2696478 Data Sheet RoHS	ROHM SMD Current Sense Resistor 0.39 ohm UCR Series 0402 [1005 Metric] 125 mW ± 1% Thick Film	Each (Supplied on Cut Tape) Cut Tape	10+ $0.686 ($0.7889) 100+ $0.401 ($0.4612) 500+ $0.298 ($0.3427) 2500+ $0.238 ($0.2737) 5000+ $0.225 ($0.2587)	Min: 10 / Mult: 10	0.39ohm	UCR Series	0402 [1005 Metric]	125mW	± 1%	Thick Film	-	0ppm/°C to +200ppm/°C	1.02mm	-	0.5mm	0.37mm	-55°C	155°C	AEC-Q200
FPS 4-T220 0R005 S 1% Q	2565568 Data Sheet	VPG FOIL RESISTORS SMD Current Sense Resistor Screw 0.005 ohm FPS 4-T220 Series TO-263 (D2PAK) 15 W ± 1%	Each	1+ $69.960 ($80.454) 2+ $60.380 ($69.437) 3+ $51.900 ($59.685) 5+ $50.520 ($58.098)	Min: 1 / Mult: 1	0.005ohm	FPS 4-T220 Series	TO-263 (D2PAK)	15W	± 1%	Metal Foil	-	± 25ppm/K	10.16mm	-	12.7mm	4mm	-40°C	130°C	-
LTR100LJZPFSR027	3924545 Data Sheet RoHS	ROHM SMD Current Sense Resistor 0.027 ohm LTR Series 1225 [3264 Metric] 4 W ± 1% Thick Film	Each (Supplied on Cut Tape) Cut Tape	10+ $1.910 ($2.1965) 100+ $1.290 ($1.4835) 500+ $0.983 ($1.1304) 1000+ $0.864 ($0.9936) 2000+ $0.859 ($0.9878) More Pricing...	Min: 10 / Mult: 10	0.027ohm	LTR Series	1225 [3264 Metric]	4W	± 1%	Thick Film	-	0ppm/°C to +200ppm/°C	3.2mm	-	6.4mm	0.58mm	-65°C	155°C	AEC-Q200
PE2512FKE7W0R006L	3922938 Data Sheet RoHS	YAGEO SMD Current Sense Resistor 0.006 ohm PE_L Series 2512 [6432 Metric] 2 W ± 1% Metal Film	Each (Supplied on Full Reel) Full Reel	4000+ $0.278 ($0.3197)	Min: 4000 / Mult: 4000	0.006ohm	PE_L Series	2512 [6432 Metric]	2W	± 1%	Metal Film	-	± 50ppm/°C	6.35mm	-	3.18mm	0.64mm	-55°C	170°C	AEC-Q200
RL0805FR-070R82L	3923434 Data Sheet RoHS	YAGEO SMD Current Sense Resistor 0.82 ohm RL Series 0805 [2012 Metric] 125 mW ± 1% Thick Film	Each (Supplied on Full Reel) Full Reel	5000+ $0.057 ($0.0656) 25000+ $0.046 ($0.0529) 50000+ $0.044 ($0.0506)	Min: 5000 / Mult: 5000	0.82ohm	RL Series	0805 [2012 Metric]	125mW	± 1%	Thick Film	-	± 200ppm/°C	2.01mm	-	1.25mm	0.5mm	-55°C	155°C	AEC-Q200
TLM3AER082JTE	2483615 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.082 ohm TLM Series 2512 [6432 Metric] 1 W ± 5% Metal Foil	Each (Supplied on Cut Tape) Cut Tape	10+ $0.950 ($1.0925) 100+ $0.794 ($0.9131) 1000+ $0.599 ($0.6888) 4000+ $0.435 ($0.5002)	Min: 10 / Mult: 10	0.082ohm	TLM Series	2512 [6432 Metric]	1W	± 5%	Metal Foil	-	± 100ppm/°C	6.3mm	-	3.15mm	0.55mm	-55°C	55°C	-
ERJB1CFR075U	2294073 Data Sheet RoHS	PANASONIC SMD Current Sense Resistor 0.075 ohm ERJ-B1 Series 1020 [2550 Metric] 2 W ± 1% Thick Film	Each (Supplied on Cut Tape) Cut Tape	10+ $0.875 ($1.0063) 100+ $0.842 ($0.9683) 500+ $0.815 ($0.9372) 1000+ $0.788 ($0.9062) 2500+ $0.772 ($0.8878)	Min: 10 / Mult: 10	0.075ohm	ERJ-B1 Series	1020 [2550 Metric]	2W	± 1%	Thick Film	-	± 150ppm/°C	2.5mm	-	5mm	0.55mm	-55°C	155°C	AEC-Q200
TLM2BER056JTD	2483538 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.056 ohm TLM Series 1206 [3216 Metric] 500 mW ± 5% Metal Foil	Each (Supplied on Cut Tape) Cut Tape	10+ $0.724 ($0.8326) 100+ $0.375 ($0.4312) 500+ $0.259 ($0.2978) 1000+ $0.203 ($0.2334)	Min: 10 / Mult: 10	0.056ohm	TLM Series	1206 [3216 Metric]	500mW	± 5%	Metal Foil	-	± 100ppm/°C	3.2mm	-	1.6mm	0.55mm	-55°C	55°C	-
RLP73K3AR62JTE	2805316 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.62 ohm RLP73 Series 2512 [6432 Metric] 2 W ± 5% Thick Film	Each (Supplied on Cut Tape) Cut Tape	5+ $1.390 ($1.5985) 50+ $0.715 ($0.8222) 250+ $0.545 ($0.6268) 500+ $0.464 ($0.5336) 1000+ $0.444 ($0.5106) More Pricing...	Min: 5 / Mult: 5	0.62ohm	RLP73 Series	2512 [6432 Metric]	2W	± 5%	Thick Film	-	± 200ppm/°C	6.35mm	-	3.15mm	0.74mm	-55°C	155°C	-
RLP73K3AR16JTE	2805301 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.16 ohm RLP73 Series 2512 [6432 Metric] 2 W ± 5% Thick Film	Each (Supplied on Cut Tape) Cut Tape	5+ $0.977 ($1.1236) 100+ $0.659 ($0.7578) 500+ $0.476 ($0.5474) 1000+ $0.384 ($0.4416) 2000+ $0.373 ($0.429) More Pricing...	Min: 5 / Mult: 5	0.16ohm	RLP73 Series	2512 [6432 Metric]	2W	± 5%	Thick Film	-	± 200ppm/°C	6.35mm	-	3.15mm	0.74mm	-55°C	155°C	-
RLP73K2BR75JTD	2805291 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.75 ohm RLP73 Series 1206 [3216 Metric] 500 mW ± 5% Thick Film	Each (Supplied on Cut Tape) Cut Tape	10+ $0.253 ($0.291) 100+ $0.127 ($0.1461) 500+ $0.109 ($0.1253) 1000+ $0.091 ($0.1046) 2500+ $0.087 ($0.100) More Pricing...	Min: 10 / Mult: 10	0.75ohm	RLP73 Series	1206 [3216 Metric]	500mW	± 5%	Thick Film	-	± 200ppm/°C	3.2mm	-	1.6mm	0.55mm	-55°C	155°C	-
TLRP3A20CR006FTE	3828631 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.006 ohm TLRP Series 2512 [6432 Metric] 2 W ± 1% Metal Strip	Each (Supplied on Cut Tape) Cut Tape	10+ $0.594 ($0.6831) 100+ $0.428 ($0.4922) 500+ $0.348 ($0.4002) 1000+ $0.278 ($0.3197) 2000+ $0.274 ($0.3151) More Pricing...	Min: 10 / Mult: 10	0.006ohm	TLRP Series	2512 [6432 Metric]	2W	± 1%	Metal Strip	-	± 25ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	AEC-Q200
RL73K1JR10JTD	8867364RL Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.1 ohm RL73 Series 0603 [1608 Metric] 100 mW ± 5% Thick Film	Each (Supplied on Cut Tape) Re-Reel Packaging Options	500+ $0.099 ($0.1138) 1000+ $0.086 ($0.0989) 2500+ $0.075 ($0.0862) 5000+ $0.064 ($0.0736) 25000+ $0.060 ($0.069) More Pricing...	Min: 500 / Mult: 10	0.1ohm	RL73 Series	0603 [1608 Metric]	100mW	± 5%	Thick Film	-	± 200ppm/°C	1.6mm	-	0.85mm	0.45mm	-55°C	125°C	-
ERJB1CFR082U	2294074 Data Sheet RoHS	PANASONIC SMD Current Sense Resistor 0.082 ohm ERJ-B1 Series 1020 [2550 Metric] 2 W ± 1% Thick Film	Each (Supplied on Cut Tape) Cut Tape	10+ $1.600 ($1.840) 100+ $1.400 ($1.610) 500+ $1.160 ($1.334) 1000+ $1.040 ($1.196) 2500+ $0.956 ($1.0994) More Pricing...	Min: 10 / Mult: 10	0.082ohm	ERJ-B1 Series	1020 [2550 Metric]	2W	± 1%	Thick Film	-	± 150ppm/°C	2.5mm	-	5mm	0.55mm	-55°C	155°C	AEC-Q200
TLM3AER01FTE	2483617 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.01 ohm TLM Series 2512 [6432 Metric] 1 W ± 1% Metal Foil	Each (Supplied on Cut Tape) Cut Tape	10+ $0.864 ($0.9936) 100+ $0.848 ($0.9752) 500+ $0.643 ($0.7394) 1000+ $0.529 ($0.6083)	Min: 10 / Mult: 10	0.01ohm	TLM Series	2512 [6432 Metric]	1W	± 1%	Metal Foil	-	± 100ppm/°C	6.3mm	-	3.15mm	0.58mm	-55°C	55°C	-
TLM3ADR043FTE	2483632 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.043 ohm TLM Series 2512 [6432 Metric] 1 W ± 1% Metal Foil	Each (Supplied on Cut Tape) Cut Tape	10+ $1.040 ($1.196) 100+ $0.724 ($0.8326) 500+ $0.519 ($0.5968) 1000+ $0.438 ($0.5037)	Min: 10 / Mult: 10	0.043ohm	TLM Series	2512 [6432 Metric]	1W	± 1%	Metal Foil	-	± 50ppm/°C	6.3mm	-	3.15mm	0.55mm	-55°C	55°C	-
GMR100HTBFER015	2808331 Data Sheet RoHS	ROHM SMD Current Sense Resistor 0.015 ohm GMR Series 2512 [6432 Metric] 3 W ± 1% Metal Strip	Each (Supplied on Cut Tape) Cut Tape	5+ $3.070 ($3.5305) 50+ $1.650 ($1.8975) 250+ $1.210 ($1.3915) 500+ $1.200 ($1.380) 1000+ $1.180 ($1.357) More Pricing...	Min: 5 / Mult: 5	0.015ohm	GMR Series	2512 [6432 Metric]	3W	± 1%	Metal Strip	-	± 20ppm/°C	6.4mm	-	3.2mm	0.4mm	-65°C	170°C	AEC-Q200
RLP73V3AR011FTDF	2805344 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.011 ohm RLP73 Series 2512 [6432 Metric] 2 W ± 1% Thick Film	Each (Supplied on Cut Tape) Cut Tape	1+ $1.310 ($1.5065) 10+ $1.030 ($1.1845) 25+ $0.929 ($1.0683) 50+ $0.837 ($0.9626) 100+ $0.691 ($0.7946) More Pricing...	Min: 1 / Mult: 1	0.011ohm	RLP73 Series	2512 [6432 Metric]	2W	± 1%	Thick Film	-	± 600ppm/°C	6.35mm	-	3.15mm	0.74mm	-55°C	155°C	-
MCLRP12DTDSR039	2827167 Data Sheet RoHS	MULTICOMP PRO SMD Current Sense Resistor 0.039 ohm MCLRP Series 2512 [6432 Metric] 2 W ± 0.5% Metal Strip	Each (Supplied on Full Reel) Full Reel Packaging Options	4000+ $0.152 ($0.1748)	Min: 4000 / Mult: 4000	0.039ohm	MCLRP Series	2512 [6432 Metric]	2W	± 0.5%	Metal Strip	-	± 50ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	-
MCLRP12DTDSR040	2827168 Data Sheet RoHS	MULTICOMP PRO SMD Current Sense Resistor 0.04 ohm MCLRP Series 2512 [6432 Metric] 2 W ± 0.5% Metal Strip	Each (Supplied on Full Reel) Full Reel Packaging Options	4000+ $0.194 ($0.2231) 20000+ $0.185 ($0.2128) 40000+ $0.176 ($0.2024) 60000+ $0.170 ($0.1955)	Min: 4000 / Mult: 4000	0.04ohm	MCLRP Series	2512 [6432 Metric]	2W	± 0.5%	Metal Strip	-	± 50ppm/°C	6.4mm	-	3.2mm	0.7mm	-55°C	170°C	-
LTR18EZPFSR091	3254953 Data Sheet RoHS	ROHM SMD Current Sense Resistor 0.091 ohm LTR Series 0612 [1632 Metric] 1.5 W ± 1% Thick Film	Each (Supplied on Cut Tape) Cut Tape	10+ $0.517 ($0.5946) 100+ $0.391 ($0.4496) 500+ $0.309 ($0.3554) 1000+ $0.300 ($0.345) 2500+ $0.291 ($0.3346) More Pricing...	Min: 10 / Mult: 10	0.091ohm	LTR Series	0612 [1632 Metric]	1.5W	± 1%	Thick Film	-	0ppm/°C to +150ppm/°C	1.6mm	-	3.2mm	0.58mm	-55°C	155°C	AEC-Q200
73L2R47J	3805455 Data Sheet RoHS	CTS SMD Current Sense Resistor 0.47 ohm 73Lx Series 0603 [1608 Metric] 100 mW ± 5% Thick Film	Each (Supplied on Cut Tape) Cut Tape	10+ $0.154 ($0.1771) 100+ $0.060 ($0.069) 500+ $0.037 ($0.0426) 1000+ $0.026 ($0.0299) 2500+ $0.024 ($0.0276)	Min: 10 / Mult: 10	0.47ohm	73Lx Series	0603 [1608 Metric]	100mW	± 5%	Thick Film	-	± 300ppm/°C	1.6mm	-	0.85mm	0.5mm	-55°C	155°C	-
RLP73K3AR12JTE	2116452 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.12 ohm RLP73 Series 2512 [6432 Metric] 2 W ± 5% Thick Film	Each Packaging Options	5+ $1.010 ($1.1615) 50+ $0.837 ($0.9626) 250+ $0.562 ($0.6463) 500+ $0.408 ($0.4692) 1000+ $0.330 ($0.3795) More Pricing...	Min: 5 / Mult: 5	0.12ohm	RLP73 Series	2512 [6432 Metric]	2W	± 5%	Thick Film	-	± 200ppm/°C	6.35mm	-	3.15mm	0.74mm	-55°C	155°C	-
TLM2HER056JTE	2483576 Data Sheet RoHS	CGS - TE CONNECTIVITY SMD Current Sense Resistor 0.056 ohm TLM Series 2010 [5025 Metric] 750 mW ± 5% Metal Foil	Each (Supplied on Cut Tape) Cut Tape	10+ $0.225 ($0.2587)	Min: 10 / Mult: 10	0.056ohm	TLM Series	2010 [5025 Metric]	750mW	± 5%	Metal Foil	-	± 100ppm/°C	5mm	-	2.5mm	0.55mm	-55°C	55°C	-
