We offer a choice of isolated thick film Zero Ohm Network Resistors with convex, concave, or flat form factors. Below are examples of the ranges offered by our manufacturers:

The Panasonic EXB28 and EXB38 series are isolated thick film chip resistor networks with convex termination. These integrated discrete resistors can effectively reduce PCB space with high component reliability and more efficiency for pick and place applications.

The Bourns CAT/CAY 16 Series of zero ohm chip resistor arrays are available with convex or concave terminals, 2,4, or 8 isolated elements, and a resistance tolerance of ±1 % or ±5 %.

The Multicomp range of thick film isolated, convex array chip resistors are of small size and light weight, offering high quality, reliable performance.

Yageo array chip resistors are constructed on top of a high-grade ceramic body. Internal metal electrodes are added at each end to make contact with the thick film resistive element. The composition of the resistive element is a noble metal embedded into a glass and covered by a second glass to prevent environment influences. The resistor is laser trimmed to the rated resistance value. The resistor is covered with a protective epoxy coat, finally the two external terminations (matte tin on Ni-barrier) are added.

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price (Incl GST)	Resistor Case / Package	Resistor Technology	Network Circuit Type	Resistor Terminals	No. of Resistors	Current Rating	Power Rating per Resistor	Resistor Mounting	Product Range	Product Length	Product Width	Product Height	Operating Temperature Min	Operating Temperature Max

CAY10A-000J4LF	3769776 Data Sheet RoHS	BOURNS Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.210($0.2415) 100+ $0.073($0.084) 500+ $0.050($0.0575) 2500+ $0.045($0.0518) 5000+ $0.039($0.0448) More Pricing...	0804 [2010 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	CAY10A-LF Series	2mm	1mm	0.4mm	-55°C	125°C
MCPNF43JT-XR0R0	4006482 Data Sheet RoHS	MULTICOMP PRO Zero Ohm Network Resistor Jumper 0603 [1608 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.076($0.0874) 100+ $0.049($0.0564) 500+ $0.039($0.0448) 1000+ $0.031($0.0356) 2500+ $0.028($0.0322)	0603 [1608 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	-	Surface Mount Device	-	3.2mm	1.55mm	0.55mm	-55°C	155°C
EXB28VR000X	2060028 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.135($0.1552) 100+ $0.088($0.1012) 500+ $0.070($0.0805) 2500+ $0.061($0.0702) 5000+ $0.049($0.0564)	0402 [1005 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	EXB-28V Series	1.02mm	0.5mm	0.35mm	-55°C	125°C
EXB38VR000V	2060083 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.127($0.1461) 100+ $0.083($0.0954) 500+ $0.063($0.0724) 1000+ $0.057($0.0656) 2500+ $0.056($0.0644)	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	EXB-38V Series	3.2mm	1.6mm	0.5mm	-55°C	125°C
CAY10-000J4LF	2663510 Data Sheet RoHS	BOURNS Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.041($0.0472) 100+ $0.027($0.031) 500+ $0.020($0.023) 2500+ $0.018($0.0207) 5000+ $0.017($0.0196) More Pricing...	0804 [2010 Metric]	-	Isolated	Convex	4Resistors	-	62.5mW	Surface Mount Device	CAY10 Series	2mm	1mm	0.35mm	-55°C	125°C
TC124-JR-070RL	1779399 Data Sheet RoHS	YAGEO Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.267($0.307) 100+ $0.106($0.1219) 500+ $0.070($0.0805) 2500+ $0.060($0.069) 5000+ $0.050($0.0575)	0402 [1005 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	62.5mW	Surface Mount Device	TC Series	1.02mm	0.5mm	0.4mm	-55°C	125°C
EXB2HVR000V	2060063 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Convex 8 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.388($0.4462) 100+ $0.259($0.2978) 500+ $0.198($0.2277) 1000+ $0.190($0.2185) 2500+ $0.183($0.2104)	0402 [1005 Metric]	Thick Film	Isolated	Convex	8Resistors	1A	63mW	Surface Mount Device	EXB-2HV Series	1.02mm	0.5mm	0.45mm	-55°C	125°C
TC164-JR-070RL	9234675 Data Sheet RoHS	YAGEO Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.220($0.253) 100+ $0.090($0.1035) 500+ $0.061($0.0702) 1000+ $0.052($0.0598) 2500+ $0.051($0.0586)	1206 [3216 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	62.5mW	Surface Mount Device	TC Series	3.2mm	1.6mm	0.6mm	-55°C	155°C
CAT16-000J4LF	2321719 Data Sheet RoHS	BOURNS Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.083($0.0954) 100+ $0.059($0.0678) 500+ $0.056($0.0644) 1000+ $0.055($0.0632) 2500+ $0.052($0.0598)	1206 [3216 Metric]	-	Isolated	Concave	4Resistors	-	62mW	Surface Mount Device	CAT16 Series	3.2mm	1.6mm	0.5mm	-55°C	125°C
YC248-JR-070RL	1377038 Data Sheet RoHS	YAGEO Zero Ohm Network Resistor Jumper 0616 [1640 Metric] Thick Film Isolated Convex 8 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.192($0.2208) 100+ $0.126($0.1449) 500+ $0.098($0.1127) 1000+ $0.085($0.0978) 2500+ $0.084($0.0966)	0616 [1640 Metric]	Thick Film	Isolated	Convex	8Resistors	2A	62.5mW	Surface Mount Device	YC Series	4mm	1.6mm	0.45mm	-55°C	155°C
CAY16-000J4LF	2321738 Data Sheet RoHS	BOURNS Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.095($0.1092) 100+ $0.061($0.0702) 500+ $0.046($0.0529) 1000+ $0.041($0.0472) 2500+ $0.039($0.0448)	1206 [3216 Metric]	-	Isolated	Convex	4Resistors	-	62mW	Surface Mount Device	CAY16 Series	3.2mm	1.6mm	0.5mm	-55°C	125°C
CAT10-000J4LF	2908138 Data Sheet RoHS	BOURNS Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Isolated Concave 4 Resistors	Each	10+ $0.070($0.0805) 100+ $0.045($0.0518) 500+ $0.043($0.0494) 2500+ $0.040($0.046) 5000+ $0.038($0.0437) More Pricing...	0804 [2010 Metric]	-	Isolated	Concave	4Resistors	-	63mW	Surface Mount Device	CAT10 Series	2mm	1mm	0.4mm	-55°C	125°C
CAY10A-000J2LF	3769775 Data Sheet RoHS	BOURNS Zero Ohm Network Resistor Jumper 0404 [1010 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.199($0.2288) 100+ $0.082($0.0943) 500+ $0.052($0.0598) 2500+ $0.046($0.0529) 5000+ $0.037($0.0426) More Pricing...	0404 [1010 Metric]	Thick Film	Isolated	Convex	2Resistors	1A	63mW	Surface Mount Device	CAY10A-LF Series	1mm	1mm	0.35mm	-55°C	125°C
CAT16A-000J4LF	3754737 Data Sheet RoHS	BOURNS RES N/W ISOLATED 0R 0.063W 3216	Each (Supplied on Cut Tape) Cut Tape	1+ $0.259($0.2978) 25+ $0.229($0.2633) 100+ $0.203($0.2334) 250+ $0.126($0.1449) 500+ $0.104($0.1196) More Pricing...	1206 [3216 Metric]	Thick Film	Isolated	Concave	-	1A	63mW	Surface Mount Device	-	-	-	0.55mm	-	125°C
YC122-JR-070RL	3497067 Data Sheet RoHS	YAGEO Zero Ohm Network Resistor Jumper 0404 [1010 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.043($0.0494) 100+ $0.029($0.0333) 500+ $0.022($0.0253) 2500+ $0.020($0.023) 5000+ $0.018($0.0207)	0404 [1010 Metric]	Thick Film	Isolated	Convex	2Resistors	500mA	62.5mW	Surface Mount Device	YC Series	1mm	1mm	0.3mm	-55°C	155°C
EXB24VR000X	4014621 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.093($0.107) 100+ $0.061($0.0702) 500+ $0.046($0.0529) 2500+ $0.041($0.0472) 5000+ $0.038($0.0437) More Pricing...	0402 [1005 Metric]	Thick Film	Isolated	Convex	2Resistors	1A	63mW	Surface Mount Device	EXB-24V Series	1mm	1mm	0.35mm	-55°C	125°C
EXB14VR000X	4632629 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 0302 [0806 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.253($0.291) 100+ $0.166($0.1909) 500+ $0.129($0.1484) 2500+ $0.111($0.1277) 5000+ $0.093($0.107) More Pricing...	0302 [0806 Metric]	Thick Film	Isolated	Convex	2Resistors	500mA	31mW	Surface Mount Device	EXB-14V Series	0.8mm	0.6mm	0.35mm	-55°C	125°C
EXBN8VR000X	4757250 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	1+ $0.266($0.3059) 10+ $0.167($0.192) 100+ $0.110($0.1265) 500+ $0.084($0.0966) 1000+ $0.070($0.0805) More Pricing...	0402 [1005 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	31mW	Surface Mount Device	EXB-N8V Series	1.02mm	0.5mm	0.45mm	-55°C	125°C
EXBV8VR000V	4544164 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 0603 [1608 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.229($0.2633) 100+ $0.151($0.1736) 500+ $0.116($0.1334) 2500+ $0.100($0.115) 5000+ $0.082($0.0943) More Pricing...	0603 [1608 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	63mW	Surface Mount Device	EXB-V8V Series	1.6mm	0.85mm	0.6mm	-55°C	125°C
EXBN8VR000X	4757017 Data Sheet RoHS	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Full Reel) Full Reel	10000+ $0.067($0.077) 50000+ $0.051($0.0586) 100000+ $0.041($0.0472)	0402 [1005 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	31mW	Surface Mount Device	EXB-N8V Series	1.02mm	0.5mm	0.45mm	-55°C	125°C
MP000986	3228734 Data Sheet RoHS	MULTICOMP PRO Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	1+ $0.043($0.0494)	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	100mW	Surface Mount Device	-	3.2mm	1.6mm	0.55mm	-55°C	155°C
YC124-JR-070RL	9235221 Data Sheet RoHS	YAGEO Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.070($0.0805) 100+ $0.045($0.0518) 500+ $0.034($0.0391) 2500+ $0.031($0.0356) 5000+ $0.026($0.0299)	0804 [2010 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	62.5mW	Surface Mount Device	YC Series	1.02mm	0.5mm	0.45mm	-55°C	125°C
YC164-JR-070RL	9234381 Data Sheet RoHS	YAGEO Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.074($0.0851) 100+ $0.049($0.0564) 500+ $0.038($0.0437) 1000+ $0.033($0.0379) 2500+ $0.032($0.0368)	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	62.5mW	Surface Mount Device	YC Series	3.2mm	1.6mm	0.6mm	-55°C	155°C
MP005619	3550043 Data Sheet RoHS	MULTICOMP PRO Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.068($0.0782) 100+ $0.045($0.0518) 500+ $0.035($0.0402) 1000+ $0.031($0.0356) 2500+ $0.027($0.031)	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	-	3.2mm	1.6mm	0.5mm	-55°C	155°C
MP005575	3549994 Data Sheet RoHS	MULTICOMP PRO Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+ $0.059($0.0678) 100+ $0.039($0.0448) 500+ $0.029($0.0333) 2500+ $0.023($0.0264) 5000+ $0.022($0.0253)	0804 [2010 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	-	2mm	1mm	0.45mm	-55°C	155°C
