EV76R77A PIC32CM LS60 Curiosity Pro

The EV76R77A Curiosity Pro Evaluation Kit is engineered for embedded-system designers and security-oriented developers working with the PIC32CM LS60 microcontroller, featuring an Arm® Cortex®‑M23 core, integrated TrustZone® and TrustFLEX ECC608 secure subsystem. Designed for ultra‑low‑power operation, the kit enables evaluation and prototyping of secure IoT, sensing, and edge applications requiring hardware cryptography and low energy consumption.

The platform integrates an on‑board embedded debugger (EDBG) with SWD, virtual COM, Data Gateway Interface, and mass‑storage boot—eliminating external tools. Its embedded current‑measurement (XAM) circuitry, with four selectable measurement ranges from nano‑amps to hundreds of milliamps, connects seamlessly to MPLAB Data Visualizer, enabling precise energy profiling.

Designed for rapid hardware and firmware development, the board includes Arduino Uno, mikroBUS, and extension headers for plug-and-play sensor integration and prototyping. Powered via USB or external 5 V input with jumper‑selectable sources, the kit supports realistic real-world testing. This kit is ideal for embedded software engineers, system integrators, and IoT architects exploring TrustZone security, secure boot, cryptographic acceleration, and ultra‑low‑power design in a unified ecosystem.
