MC 1,5/ 2-ST-5,08

Pluggable Terminal Block, 5.08 mm, 2 Ways, 28AWG to 16AWG, 1.5 mm², Screw, 8 A

MC 1,5/ 2-ST-5,08 - Pluggable Terminal Block, 5.08 mm, 2 Ways, 28AWG to 16AWG, 1.5 mm², Screw, 8 A

Image is for illustrative purposes only. Please refer to product description.

Manufacturer Part No:
MC 1,5/ 2-ST-5,08
Order Code:
2776517
Product Range
COMBICON Series
Also Known As:
1836079, GTIN UPC EAN: 4017918110956
See all Technical Docs

Product Overview

The MC 1,5/ 2-ST-5,08 from Phoenix Contact is a 5.08mm pitch, 2 pole pluggable terminal block. The plug-in direction parallel to the conductor axis with wire size ranging from 28AWG to 16AWG.
  • Nominal current is 8A
  • Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 400V
  • Rated surge voltage (III/3) is 4KV, (III/2) is 4KV, (II/2) is 4KV
  • Green colour polyamide insulating material, flammability rating according to UL94 V0
  • Nominal cross section is 1.5mm²
  • Contact surface is tin
  • Stripping length is 7mm
  • CSA, VDE, CCA, cULus standards
  • Screw connection with tension sleeve

Applications

Industrial

Product Information

Want to see similar products? Simply select your required attributes below and hit the button ×


:
5.08mm

:
2Ways

:
28AWG to 16AWG

:
1.5mm²

:
Screw

:
8A

:
300V

:
COMBICON Series

Find similar products Choose and modify the attributes above to find similar products.

Technical Docs (1)

Also Known As

1836079, GTIN UPC EAN: 4017918110956
