LW Y1SG-BFOO-EKFM-1
LED, InGaN on Sapphire, White, SMD, 20 mA, 3.3 V, 1.6 cd
Image is for illustrative purposes only. Please refer to product description.
ManufacturerAMS OSRAM GROUP
Manufacturer Part NoLW Y1SG-BFOO-EKFM-1Copy
Manufacturer Standard Lead Time14 weeks
Order Code4308419
Product RangeMicro SIDELED 2808 Series
Also Known AsLW Y1SG-BFOO-EKFM-1-20-R18-Z, Q65111A8461
Your Part Number
2,330 total stock globally
Need more?
2,330 Delivery in 3-5 Business Days(UK stock)
| Quantity | Price (Incl GST) |
|---|---|
| 5+ | $1.530 ($1.7595) |
| 10+ | $0.765 ($0.8798) |
| 25+ | $0.711 ($0.8176) |
| 50+ | $0.656 ($0.7544) |
| 100+ | $0.601 ($0.6912) |
| 150+ | $0.590 ($0.6785) |
| 200+ | $0.578 ($0.6647) |
| 250+ | $0.566 ($0.6509) |
Price for:Each (Supplied on Cut Tape)
Minimum: 5
Multiple: 5
$7.65 ($8.80 inc GST)
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
ManufacturerAMS OSRAM GROUP
Manufacturer Part NoLW Y1SG-BFOO-EKFM-1Copy
Manufacturer Standard Lead Time14 weeks
Order Code4308419
Product RangeMicro SIDELED 2808 Series
Also Known AsLW Y1SG-BFOO-EKFM-1-20-R18-Z, Q65111A8461
Technical Datasheet
LED ColourWhite
LED MountingSMD
Bulb Size-
Forward Current If20mA
Forward Voltage3.3V
Luminous Intensity1.6cd
Viewing Angle120°
Lens ShapeRectangular
Product RangeMicro SIDELED 2808 Series
Automotive Qualification Standard-
SVHCNo SVHC (21-Jan-2025)
Product Overview
LW Y1SG-BFOO-EKFM-1 is a Micro SIDELED® 2808 SMT white LED with side emission. Due to its low package height, it is ideal for applications in limited space environments. Typical applications include access control & security, appliances & tools, factory automation, home & building automation, material processing, projection & display and robotics.
- Luminous intensity of ≥ 1600mcd(IF = 20mA)
- White SMT package, coloured diffused silicone resin
- InGaN on sapphire chip technology
- 120° (Lambertian emitter) typical radiation
- Cx = 0.30, Cy = 0.28 acc. to CIE 1931 (white colour)
- 45lm/W optical efficacy
- Corrosion robustness class 1B
- 2kV ESD according to ANSI/ESDA/JEDEC JS-001 (HBM, class 2)
Technical Specifications
LED Colour
White
Bulb Size
-
Forward Voltage
3.3V
Viewing Angle
120°
Product Range
Micro SIDELED 2808 Series
MSL
MSL 4 - 72 hours
LED Mounting
SMD
Forward Current If
20mA
Luminous Intensity
1.6cd
Lens Shape
Rectangular
Automotive Qualification Standard
-
SVHC
No SVHC (21-Jan-2025)
Technical Docs (1)
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:Taiwan
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:Taiwan
Country in which last significant manufacturing process was carried out
Tariff No:85414100
US ECCN:EAR99
EU ECCN:NLR
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (21-Jan-2025)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.00001
