ERSA 0102CDLF16/SB

Soldering Iron Tip, Chisel, 1.6 mm

ERSA 0102CDLF16/SB
ERSA 0102CDLF16/SB
ERSA 0102CDLF16/SB
ERSA 0102CDLF16/SB
×

Image is for illustrative purposes only. Please refer to product description.

Manufacturer:
ERSA ERSA
Manufacturer Part No:
0102CDLF16/SB
Order Code:
1203971
  • Enter your custom part number in the textbox above
  • Maximum Part Numbers added.
    Delete older entries to add more.

Part Number Saved

Part Number Saved

Technical Datasheet:
0102CDLF16/SB   Datasheet
ECAD / MCAD
Supply Frame Models Link
See all Technical Docs

Product Information

Want to see similar products? Simply select your required attributes below and hit the button ×


:
1.6mm

:
Chisel

:
I-Tool Soldering Iron

Find similar products Choose and modify the attributes above to find similar products.

Technical Documents (2)

Product Overview

The 0102CDLF16/SB is a chisel point Soldering Tip and lead-free soldering will require higher working temperatures. In addition, the higher tin (Sn) content in the lead-free solder will greatly increase the stress degradation to the solder tip, thereby decreasing the life of the tip considerably. In order to increase the tip life, soldering tip manufacturers must adjust the amount of iron (Fe) plating on the tips. The base material made of highly conductive electrolytic copper ensures unhindered heat transfer from the heating element to the ERSADUR-LF coating.
  • 24V voltage rating
  • 150W ±10% power rating
  • Approximately 9 seconds to 350°C heating time
  • 30.5mm total length
  • Antistatic according to MIL-SPEC/ESA standards with integrated ID and standby function model

Applications

Maintenance & Repair

778 total stock globally Need more?

778 UK stock available for 5-8 business days delivery

Due to market conditions delivery times are for general guidance only and may be subject to change at short notice

$15.52 ( $17.85  Inc. GST)
