D9010CEIC/R-B5P-001-A/R-B6P-001-L-AU

D9010CEIC/R-B5P-001-A/R-B6P-001-L-AU is a D9010CEIC and R-B5P-001-A node locked perpetual license with a R-B6P-001-L 12-month support subscription. D9010CEIC is an OIF-CEI 4.0 compliance application software for Infiniium real-time oscilloscopes. It is designed to accurately and quickly characterize PAM4 and NRZ electrical signals as outlined in the OIF-CEI 4.0 standard. Performing PAM4 and NRZ measurements as per requirements of developing industry standards can be challenging and difficult. You can save time and maximize the accuracy of your PAM4 measurements by using the Keysight D9010CEIC OIF-CEI 4.0 Compliance Application with your Z-Series real-time oscilloscope. This tool will allow you to measure your Pulse Amplitude Modulation 4-Level (PAM4) and NRZ design according to the measurement requirements detailed in the OIF-CEI 4.0 standard.

• Operates on the Keysight UXR and Z-series real-time oscilloscopes
• Automatic HTML report generation
• Test all or selected parameters to compliance limits or custom limits
• Makes nearly 140 tests
• Level-based (noise, linearity), eye-based (EW6, EH6), jitter, and return loss tests
