0926-1-15-20-75-14-11-0
Contact, Spring Loaded Pin, Point, 2 A, 5.21 mm, 25 g
Image is for illustrative purposes only. Please refer to product description.
ManufacturerMILL-MAX
Manufacturer Part No0926-1-15-20-75-14-11-0
Order Code2751182
Product RangeTUK SGACK902S Keystone Coupler
Technical Datasheet
Available to Order
Manufacturer Standard Lead Time: 7 week(s)
Notify me when back in stock
| Quantity | Price (Incl GST) |
|---|---|
| 1+ | $1.430 ($1.6445) |
| 10+ | $1.210 ($1.3915) |
| 25+ | $1.140 ($1.311) |
| 50+ | $1.120 ($1.288) |
Price for:Each
Minimum: 1
Multiple: 1
$1.43 ($1.64 inc GST)
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
ManufacturerMILL-MAX
Manufacturer Part No0926-1-15-20-75-14-11-0
Order Code2751182
Product RangeTUK SGACK902S Keystone Coupler
Technical Datasheet
Connector TypeSpring Loaded Pin
Centreline Spacing-
Connector Tip StylePoint
Current Rating2A
Overall Length5.21mm
Spring Force Initial25g
Spring Force Working Travel60g
Product RangeTUK SGACK902S Keystone Coupler
SVHCNo SVHC (12-Jan-2017)
Product Overview
The 0926-1-15-20-75-14-11-0 from Mill Max is a discrete spring loaded pin contact. This low profile spring pin features a 0.0275" mid-stroke and 0.055" maximum stroke, endurance of 1,000,000cycles and a rated current of 2A continuous use (3A peak). Ideal for applications where above board height is limited. The low profile options maintain the quality and reliability of current Mill-Max spring pins by utilizing the same technology & internal spring components.
- Low profile, standard stroke, solder mount in 0.074 minimum mounting hole
- Force at mid stroke is 60g
- Initial force (pre-load) is 25g
- Gold plated beryllium copper spring
- Copper alloy with gold finish sleeve & plunger material
- Maximum contact resistance is 20mohm
- Operating temperature range from -55°C to +125°C
Technical Specifications
Connector Type
Spring Loaded Pin
Connector Tip Style
Point
Overall Length
5.21mm
Spring Force Working Travel
60g
SVHC
No SVHC (12-Jan-2017)
Centreline Spacing
-
Current Rating
2A
Spring Force Initial
25g
Product Range
TUK SGACK902S Keystone Coupler
Technical Docs (1)
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Tariff No:85366990
US ECCN:EAR99
EU ECCN:NLR
RoHS Compliant:Y-Ex
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (12-Jan-2017)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.000064
