878321420
Pin Header, Signal, 2 mm, 2 Rows, 14 Contacts, Surface Mount Straight, Milli-Grid 87832
Image is for illustrative purposes only. Please refer to product description.
ManufacturerMOLEX
Manufacturer Part No878321420
Order Code1508493
Product RangeMilli-Grid 87832
Also Known As87832-1420, GTIN UPC EAN: 822348231973
Technical Datasheet
1,805 total stock globally
Need more?
1805 Delivery in 10-14 Business Days(US stock)
Available until stock is exhausted
| Quantity | Price (Incl GST) |
|---|---|
| 1+ | $2.190 ($2.5185) |
| 10+ | $1.970 ($2.2655) |
| 96+ | $1.940 ($2.231) |
| 256+ | $1.930 ($2.2195) |
| 10016+ | $1.880 ($2.162) |
Price for:Each
Minimum: 1
Multiple: 1
$2.19 ($2.52 inc GST)
Enter Your Part No/Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
This number will be added to the Order Confirmation, Invoice, Dispatch note, Web confirmation Email and Product Label.
Product Information
ManufacturerMOLEX
Manufacturer Part No878321420
Order Code1508493
Product RangeMilli-Grid 87832
Also Known As87832-1420, GTIN UPC EAN: 822348231973
Technical Datasheet
Connector SystemsSignal
Contact Termination TypeSurface Mount Straight
Product RangeMilli-Grid 87832
Connector ShroudShrouded
Contact MaterialPhosphor Bronze
Contact PlatingGold Plated Contacts
Connector Type0
Alternatives for 878321420
2 Products Found
Product Overview
The 878321420 is a 14-circuit shrouded vertical surface mount Milli-Grid™ PCB Header with phosphor bronze, 0.38µm gold plating mating, tin plating termination and nylon resin. It is lead-free device with locking windows and centre polarization slot, PCB locator. It is high-density connector system based on a 2.00 by 2.00mm grid pattern that offers complete design flexibility for wire-to-board, board-to-board and cable-to-board applications.
- 94V-0 Flammability rating
- 2A Current per contact (maximum)
- 100 Mating cycles durability
- -55 to 105°C Operating temperature range
Applications
Consumer Electronics, Communications & Networking, Automotive, Industrial
Technical Specifications
Connector Systems
Signal
Product Range
Milli-Grid 87832
Contact Material
Phosphor Bronze
Connector Type
0
Contact Termination Type
Surface Mount Straight
Connector Shroud
Shrouded
Contact Plating
Gold Plated Contacts
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:Malaysia
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:Malaysia
Country in which last significant manufacturing process was carried out
Tariff No:85369010
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:To be advised
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.001
